ASP-621 is a high accuracy, low profile single point platform load cell for platform weighing.ASP-621 is a high accuracy, low profile single point platform load cell for platform weighing.ASP-621 is a high accuracy, low profile single point platform load cell for platform weighing.ASP-621 is a high accuracy, low profile single point platform load cell for platform weighing.ASP-621 is a high accuracy, low profile single point platform load cell for platform weighing.
Product Type
Single Point Aluminium Load Cell
Usage
Table top scales, Counting and postal scales, Check weighers.
Material
Aluminium
Output
Analog Sensor
Theory
Resistance Sensor
Compensated Temperature
10 To 60 Celsius (oC)
Rated capacity (Kgf)
11, 15, 22.5, 45, 90
Excitation Voltage
10VDC-Maximum 15 VDC
Rated Output
2.0 mV/V
Non – Linearity
< ± 0.025 % FSO (Full scale Output)
Hysteresis
< ± 0.01 % FSO
Non-Repeatability
< ± 0.02 % FSO
Creep error (30 minutes)
< ± 0.03 % FSO
Zero Load Output
< ± 0.03 % FSO
Input Resistance
390 ±15 Ohms
Output Resistance
350 ±5 Ohms
Insulation Resistance
>1000 Mega Ohms
Cable length
3 meters
Safe Overload
150 % of Rated Capacity
Ultimate Overload
250 % of Rated Capacity
Temperature
Compensated Range
0 to 60° C
Temperature Effect on
Output
<0.0015 % FSO/° C
Temperature Effect on
Zero
< 0.002 % FSO/° C
Max. Platform Size
500 x 500 mm
Off Center Load Error
< 0.02% of FSO at 1/3 rated
load/250mm off center
Deflection
< 0.5 mm at FSO
Finish & Construction
Electroless Nickel plated Tool Steel.
Environment Protection
IP 67
